Era H1
Modular High Voltage Energy Storage System - Scalable ESS solution covering backup power supply, peak shaving, and demand management. Built with grade-A LiFePO4 battery cells and advanced BMS protection, offering flexible capacity expansion from 5.32kWh to 42.56kWh to meet diverse residential and commercial energy needs.
Capacity
10.64-42.56 kWh
Modules
2-8 pcs
Voltage
102.4V
Certifications & Standards
CE
IEC 62619
UN38.3
RoHS
MSDS
Technical Specifications
Complete technical parameters and system features
| Parameter | Specification |
|---|---|
| Model | H-U10250HV |
| Configuration | 2S - 8S (2-8 modules in series) |
| Rated Voltage | 204.8V - 819.2V (varies by configuration) |
| Rated Capacity | 52 Ah |
| Battery Module Quantity | 2 - 8 pcs |
| Rated Energy | 10.64 kWh - 42.56 kWh (expandable to 212.8kWh) |
| Voltage Range | 172.8V - 921.6V (varies by configuration) |
| Battery Type | LiFePO4 (Lithium Iron Phosphate) - Grade A |
| Standard Charging Current | 25 A |
| Max. Charging Current | 50 A |
| Peak Discharging Current | 75 A (<3000ms) |
| Communication | CAN, RS485 / WiFi, BLE (optional) |
| Working Temperature | 0°C to 45°C (Charge/Discharge) |
| Storage Temperature | -10°C to 50°C |
| Dimensions with Bracket | 465×480×504mm (2S) to 465×480×1572mm (8S) |
| Dimensions with U-Cabinet | 600×600×600mm (2S) to 600×600×1800mm (8S) |
| Weight | 136 kg (2S) to 414 kg (8S) |
| Inverter Compatibility | Compatible with mainstream inverters (Growatt, Deye, Goodwe, etc.) |
| Certifications | CE, IEC 62619, UN38.3, RoHS, MSDS |
Key Features
Outstanding advantages that make this system stand out
Modular & Scalable Design
Starting from 1 module of 102.4V 52Ah battery, users can configure the system capacity from 5.32kWh to 212.99kWh according to requirements. The flexible modular design enables easy capacity extension - simply stack 2-8 modules in series for one tower, and connect up to 5 towers in parallel to achieve maximum capacity. This scalability perfectly adapts to growing energy demands without replacing the entire system.
Advanced Safety & Reliability
Built with premium grade-A LiFePO4 battery cells known for exceptional safety and longevity. The advanced Farich BMS system automatically triggers four-layer protection to ensure powerful output and safety, including over-voltage, over-current, over-temperature, and short-circuit protection. Features pre-charge function for safe initial connection and supports peak discharging current up to 75A for reliable power delivery.
Wide Compatibility & Smart Management
Seamlessly compatible with mainstream inverters including Growatt, Deye, Goodwe, and more, making integration effortless. Equipped with multiple communication options: CAN, RS485, and optional WiFi/Bluetooth connectivity for flexible system monitoring and control. Supports remote debugging, upgrading, and pairing with inverters through the dedicated mobile app, enabling convenient energy management from anywhere.
Product Gallery
Detailed views and application scenarios
